Dial Gauge ไดอัลเกจ Mitutoyo รุ่น 2047A (0-10X0.01 มม.)
Standard Type, 10 mm Range, 0,01 mm Graduation
This is a standard dial indicator. It offers you the following benefits:
- Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools.
- No through screw holes on the frame as well as the use of an O-ring prevents water or oil penetration.
| Order No. | 2047A |
| Digital/Analog: |
Analog
|
| Inch-Metric: |
Metric
|
| Range: |
10 mm
|
| Range per rev.: |
1 mm
|
| Graduation: |
0.01
|
| Scale: |
0-50-0
|
| MPE any 1/10 revolution: |
5
|
| MPE any 1/2 revolution: |
9
|
| MPE any 1 revolution: |
10
|
| MPE measuring range: |
13
|
| H MPE (Hysteresis): |
3
|
| R MPE (Repeatability): |
3
|
| Measuring force: |
0,4-1,4
|
| Stem: |
8 mm
|
| Contact point: |
Carbide tipped, thread: M 2.5 x 0.45 mm
|
| Delivered: |
with certificate of inspection
|
| Mass: |
144
|
| Balanced dial: |
Yes
|
| fu: |
3
|
| Functions: |
ISO type
|
 |
A: 47.2 B: 65.2 C: 57 D: 18.1 E: 20 F: 16.9 G: 19.8 H: 52 I: 7.6 |
| ยี่ห้อ เครื่องมือวัด | Mitutoyo |
|---|---|
| BRANDS | MITUTOYO |
