Digimatic Indicator ไดอัลเกจดิจิตอลฝาหลังเรียบ (0-12.7X0.01 มม) Mitutoyo รุ่น 543-781B-10
พร้อมส่ง
รหัสสินค้า
1MIT-543-781B-10
ราคาพิเศษ
฿2,921.10
ราคาปรกติ
฿4,173.00
This is a standard model of indicator that is reliable and easy to use.
The ABSOLUTE Digimatic Indicator ID-S offers you the following
benefits:
- The ABSOLUTE sensor means you don‘t have to carry out origin setting every time you power it on, saving you time and hassle.
- You can access all functions by using the large, user-friendly
buttons on the front of the indicator. - Large character height of 9 mm provides good readability.
- Exceptional battery life.
| Order No. | 543-781B-10 |
| Range (mm) | 12.7 mm |
| Resolution (mm) | 0.01 mm |
| Maximum permissible error*1 (mm) | 0.02 mm |
| H MPE (Hysteresis) | 0.02 mm |
| R MPE (Repeatability) | 0.01 mm |
|
Measuring force MPL (N)
|
1.5 or less |
| Back type | Flat |
| Battery life*3 | Approx. 20,000 hours (Continuous use) Approx. 5 years (Normal use) |
| Dust/Water protection level*4 |
IP42 |
 |
| ยี่ห้อ เครื่องมือวัด | Mitutoyo |
|---|---|
| BRANDS | MITUTOYO |
