Digital Thickness Gauge เกจวัดหนาบางดิจิตอล Mitutoyo รุ่น 547-401A (0.0005, 0.001X0-12มิล)
สินค้าหมด
รหัสสินค้า
1MIT-547-401A
ราคาพิเศษ
฿17,362.89
ราคาปรกติ
฿24,804.13
This ABSOLUTE Digimatic Thickness Gauge with 1 µm digital step enables you to measure film, paper, etc., with flat contact points.
| ORDER NO. | 547-401A |
| Digital/Analog: |
Digital
|
| Inch-Metric: |
Metric
|
| Functions: |
543-700BS
|
| Range: |
0 - 12 mm
|
| Digital step: |
0.0005 mm/ 0.001 mm/ 0.1 mm
|
| Accuracy: |
±3 µm
|
| R MPE (Repeatability): |
0.002 mm
|
| Measuring force: |
≤ 3.5 N
|
| Protection: |
IP42
|
| Parallelism: |
3 µm
|
| Indicator No.: |
543-700BS
|
| Max. measuring depth: |
21 mm
|
| Scale: |
Electrostatic capacitance type absolute linear encoder
|
| Display: |
LCD, character height 11 mm
|
| Alarm: |
Low voltage, setting errors, sensor error, display overflow a.s.o.
|
| Power supply: |
1 battery CR2032 (3V)
|
| Battery life: |
Continuous use: approx. 2700h
|
| DATA/HOLD: |
Yes
|
| PRESET: |
Yes
|
| Digimatic data output: |
Yes
|
| ON/OFF: |
Yes
|
| Function lock: |
Yes
|
| GO/±NG judgement: |
Yes
|
| ABS / INC (INC ZERO): |
Yes
|
| Calculation function (with formula): |
Yes
|
| Counting direction switchable: |
Yes
|
| Digimatic S1 Bidirectional interface: |
Yes
|
| Analog bar resolution selection: |
Yes
|
| Auto Power OFF setting: |
Yes
|
| Analog bar resolution switchable: |
Yes
|
| Customizing keys: |
Yes
|
| Inch/Metric switchable: |
Yes
|
| Calibration warning function: |
Yes
|
| Digital step switchable: |
Yes
|
| Type: |
D= 6.3 mm carbide tipped
|
 |
| ยี่ห้อ เครื่องมือวัด | Mitutoyo |
|---|---|
| BRANDS | MITUTOYO |
