Inside Micrometers ไมโครมิเตอร์วัดใน 50-300 มม.Mitutoyo รุ่น 137-202
สินค้าหมด
รหัสสินค้า
1MIT-137-202
ราคาพิเศษ
฿5,136.00
ราคาปรกติ
฿7,337.14
- Wide range of inside measurements
possible by combining extension rods and
anvils with the micrometer head. - A reference gage is necessary for reference
point setting. - Two types of measuring faces are available:
with or without carbide tip. (The SERIES 337
is only available with carbide tip) - An optional reference gage, such as Gauge
Block Accessory Set, CERA inside Micro
Checker or a setting ring (nominal size
300 mm or less), is required for accurately
setting the micrometer before measuring.
(refer to pages 01-19 to 01-22, and 08-53
for details)
| Code No. | 137-202 |
| Range (mm) | 50 - 300 |
| Graduation (mm) | 0.01 |
| Spindle feed error* (μm) |
3 |
| Micrometer head stroke (mm) |
13 |
| Extension rods | 5 (13, 25, 50 (2 pcs.), 100 mm) |
| Main unit (mm) | 50 - 63 |
 |
| ยี่ห้อ เครื่องมือวัด | Mitutoyo |
|---|---|
| BRANDS | MITUTOYO |
